Spirax Sarco 1871160 TDS46M Horizontal Thermodynamic Steam Trap, 1 in Nominal, ANSI 150 Flanged End Style, Stainless Steel, With Blowdown Valve
Description
Spirax Sarco Thermodynamic Steam Trap, Horizontal, Series: TDS46M, 1 in Nominal, Flanged End Style, 160 mm Length, 1.5 to 14 bar g Pressure, Stainless Steel, 0 to 450 deg C
The TDS46M is a stainless steel, Thermodynamic Steam Trap that has been specifically designed for low capacity applications up to 46 bar g (where pipe connections permit). As standard the unit is available with either screwed, socket weld or flanged connections
SPECIFICATIONS
Brand: Spirax Sarco
Weight: 9.2 lbs
Nominal Size: 1 in
End Style: ANSI 150 Flange
Material: Stainless Steel
Max Operating Pressure: 203 psig
Max Allowable Pressure: 275 psig/up to 100 deg F
Max Allowable Temperature: 842 deg F/up to 66 psig
Length: 160 mm
Manufacturer Name: Spirax-Sarco Inc
Series: TDS46M
Type: Horizontal
Standards and Approvals: ANSI Class 150 | ASTM A216 Grade WCB | EN 10204 3.1 | European Pressure Equipment Directive 97/23/EC
Vendor: Spirax Sarco
